Performance parameters
| Model |
CYTJ45
|
|---|---|
| Shipping dimensions (L × W × H) |
12370×1700×2300mm
|
| Quality of complete machine |
12.5t
|
| Electrical installed power |
62kW
|
| Operating mode |
Electric construction + diesel emergency response
|
| Control mode |
Wireless remote control + manual control
|
| Operating voltage |
380V
|
| Operating range (W × H) |
2.8m×2.8m-5.5m×5m
|
| Chassis form |
Articulated engineering chassis
|
| Driving mode |
One-way driving + wireless remote control
|
| Drive and steering mode |
Four-wheel drive, articulated steering
|
| Minimum ground clearance |
260mm
|
| Maximum climbing gradient |
15°
|
| Turning radius |
3170mm (inside)/5360mm (outside)
|
| Maximum speed |
8-15km/h
|
| Approach/departure angle |
17°/19°
|
| Boom mode |
Double triangle + telescopic boom structure
|
| Number of booms |
1
|
| Number of rock drills |
1
|
| Power of rock drill |
18kW/22kW
|
| Maximum drilling depth |
3.4m/3.9m
|
| Borehole diameter |
Drill shank R32-Φ45mm
Drill shank R32-Φ 89mm
|
| Air displacement |
0.3-0.6m³/min
|
| Discharge pressure |
0.3-0.8MPa
|
| Flow rate |
40-120L/min
|
| Pressure |
0.5-2.5MPa
|
